• (10) Red+(3) White SMD LEDs of up-to-date technology, super bright
• Engineered lens optics
• PC lens and housing welded together to ensure a permanent and weather proof seal
• Two of standard right angle 3-prong (PL3) receptacle on the backside
• Meets DOT FMVSS 108/SAE requirements; Lens marking: I6 S2 T2 R
• Rated for 12V, tested to 13.8V
• Also available in multi-voltage 10~30V operating range, or 24V by special order only
Part No. |
Description |
Input Voltage |
LED Count |
Current Draw (A) at 13.8V |
106013R |
Grommet Mount Red Kit |
12 V |
10 Red/3 White |
0.12A |
106013R-FL |
Flange Mount Red Kit |
12 V |
10 Red/3 White |
0.12A |
906403P |
Right Angle 3 Prong Plug for 6” Oval Light |
