• Innovative Hybrid style Neon Glow Outline is incorporated with standard Stop/Tail/Turn tail light, features unique and eye-catching appearance
• New lens pattern and engineered lens optics, minimize direct lighting from shining into the eyes
• Durable PC lens and housing sonically welded and sealed by epoxy in a single unit to ensure a permanent and weather proof seal
• Grommet mount, black PVC
• Standard right angle 3-prong receptacle, fitting standard 3-prong (PL3) pigtail plug; also available in 3-pin AMP receptacle by special order
• Meets DOT FMVSS 108/SAE requirements, lens marking S2 T2 I6 R
• Rated for 12V, tested to 13.8V
|
Part No. |
Description |
Input Voltage |
Lighting Color |
LED Count |
Current Draw (A) at 13.8V |
|
|
107512A |
Amber, Grommet Kit |
12 V |
Amber |
12 |
0.21 A |
|
|
107512R |
Red, Grommet Kit |
12 V |
Red |
12 |
0.12/048 A |
|
|
107512C |
White, Grommet Kit, Back-up |
12 V |
White |
12 |
0.21 A |
|
|
107512AL |
Amber, Lamp Only |
12 V |
Amber |
12 |
0.21 A |
|
|
107512RL |
Red, Lamp Only |
12 V |
Red |
12 |
0.12/048 A |
|
|
107512CL |
White, Lamp Only, Back-up |
12 V |
White |
12 |
0.21 A |
|
|
107400G |
Grommet Only for Rectangular Tail Light |
|||||
|
906403P |
Standard Right Angle 3 Prong (PL3) Plug for All 4“ Round & 6” Oval Lights |
|||||
