combined functions of Stop, Tail (Indicator) and Turn Signal
• Stud mount, S.S. bolts over-molded in the base to ensure durability and water poof
• PC lens and ABS base
• SMD LEDs, super bright and long life span
• LED board & circuitry completely welded and sealed by epoxy to ensure permanent water
proof, Submersible
• 20cm (8”) sleeved wire; direct lead wires with ends stripped
• Meets ECE requirements for all functions (E-MARK certified)
• Rated for 12V, tested to 13.8V
• Also available in multi-voltage 10~30V operating range or 24V by special order
Part No. |
Description |
LED Count |
Input Voltage |
Lighting Color |
Current Draw (A) at 13.8V |
108010AR |
Square Combination Tail Light 12V |
5+5 |
12 V |
Red/Amber |
Red 0.12 A/0.01 A Amber 0.14 A |
108010ARM |
Square Combination Tail Light Multi-volt |
5+5 |
10-30 V |
Red/Amber |
Red 0.12 A/0.01 A Amber 0.14 A |
