4" Round LED Light Stop/Tail/Turn, Flange Mount w/ Reflex Ring 4" Round LED Light Stop/Tail/Turn, Flange Mount Plain Ring_LED Trailer Lights Manufacturers, Truck Lights China Origin

4" Round LED Light Stop/Tail/Turn, Flange Mount w/ Reflex Ring 4" Round LED Light Stop/Tail/Turn, Flange Mount Plain Ring

Brand Name:	HOJA or Privately Labelled
Input Voltage:	12V, 10~30V
Functions:	Stop, Tail, Turn
Mounting Type:	Flange Mount
Standards:	FMVSS 108/SAE,
Lens Marking:	STI
IP Rating:	IP65
Applications:	Truck, Trailer, RV, Speciality Vehicles

E-mail : info@hoja.com.cn

• Standard 4" Round STT Light series, flange mount with reflex ring or plain surface ring

• Versions of 7 LEDs and 12 LEDs; super bright SMD LEDs of long life span up to 50,000 hours

• Stop, Turn, Tail functions combined.

• Engineered lens optics

• PC lens and housing welded together to ensure a permanent and water proof seal.

• Standard right angle 3-prong plug assembly

• Right angle 3-prong plug assembly

• Meets DOT FMVSS 108/SAE requirements except Amber version of 7 LEDs (104207A)

• Rated for 12V, tested to 13.8V

• Also available in multi-voltage 10~30V operating range or 24V by special order only

Part No.	Description	Input Voltage	LED Count	LED Type	Lighting Color	Current Draw at 13.8V
104307R	Flange Mount Reflex Ring Red	12V	7	SMD	Red	0.02/0.13 A
104312R	Flange Mount Reflex Ring Red	12V	12	SMD	Red	0.02/0.19 A
104312A	Flange Mount Reflex Ring Amber	12V	12	SMD	Amber	0.02/0.19 A
104312C	Flange Mount Reflex Ring Clear White	12V	12	SMD	White	0.30 A
104307RM	Flange Mount Reflex Ring Red M.V.	12～24 V	7	SMD	Red	0.02/0.11 A
104307AM	Flange Mount Reflex Ring Amber M.V.	12～24 V	7	SMD	Amber	0.02/0.11 A
104307CM	Flange Mount Reflex Ring White M.V.	12～24 V	7	SMD	White	0.20 A
104312RM	Flange Mount Reflex Ring Red M.V.	12～24 V	12	SMD	Red	0.02/0.11 A
104312AM	Flange Mount Reflex Ring Amber M.V.	12～24 V	12	SMD	Amber	0.02/0.11 A
104312CM	Flange Mount Reflex Ring White M.V.	12～24 V	12	SMD	White	0.16 A
104607R	Flange Mount Plain Red Red	12V	7	SMD	Red	0.02/0.13 A
104612R	Flange Mount Plain Red Red	12V	12	SMD	Red	0.02/0.19 A
104612A	Flange Mount Plain Amber	12V	12	SMD	Amber	0.02/0.19 A
104612C	Flange Mount Plain Clear White	12V	12	SMD	White	0.30 A
104607RM	Flange Mount Plain Red M.V.	12～24 V	7	SMD	Red	0.02/0.11 A
104607AM	Flange Mount Plain Amber M.V.	12～24 V	7	SMD	Amber	0.02/0.11 A
104607CM	Flange Mount Plain White M.V.	12～24 V	7	SMD	White	0.20 A
104612RM	Flange Mount Plain Red M.V.	12～24 V	12	SMD	Red	0.02/0.11 A
104612AM	Flange Mount Plain Amber M.V.	12～24 V	12	SMD	Amber	0.02/0.11 A
104612CM	Flange Mount Plain White M.V.	12～24 V	12	SMD	White	0.16 A
906403P	Right Angle 3 Prong Plug for 4" Round Light
104300FL	Flange Mount Bracket with Reflex Ring only

Certificate
