• Features Stop (Brake) and Indicator (Tail) functions, ideal to use as retro-fit, a high mount third brake light or an auxiliary tail light
• 12 LEDs of super flux (P4) type, super bright and super long life span up to 100,000 hours
• PC lens and housing, heat welded together to ensure a permanent and water proof seal.
• LEDs and circuit board coated with conformal coating for excellent moisture and environmental protection
• Red color meets DOT FMVSS 108/SAE requirements for high mount third brake light
• Rated for 12V, tested to 13.8V
• Also available in multi-voltage 10~30V operating range or 24V by special order
Part No. |
Description |
Input Voltage |
LED Count |
Lighting Color |
Current Draw (mA) at 13.8V |
108312R |
Red Lens/Red LED |
12V |
12 |
Red |
15/250 mA |
108312C |
Clear Lens/White LED |
12V |
12 |
White |
15/100 mA |
108312RM |
Red Lens/Red LED, Multi-voltage |
12~24 V |
12 |
Red |
15/250 mA |
108312CM |
Clear Lens/White LED, Multi-voltage |
12~24 V |
12 |
White |
15/100 mA |
