• Available in economical version of (3) SMD LEDs and traditional (12) SMD LEDs
• Functions as clearance, side marker or identification light
• PC lens and housing sonically welded in a single lamp unit to ensure a permanent and weather proof seal
• Easy installation by snapping the lamp unit onto the base mount bracket; ideal for retrofit of traditional incandescent lights
• Base mount bracket with industry standard 3" centers; self ground and one separate lead wire for mounting to metal surfaces (two wires version by special order only)
• Meets DOT FMVSS 108/SAE requirements
• Rated for 12V, tested to 13.8V
• Also available in 24V version and 10-30V multi-voltage version by special order only
Part No. |
Description |
Input Voltage |
Lighting Color |
LED Count |
LED Type |
Current Draw(A) at 13.8V |
114003A |
Chromed Base Mount Kit |
12V |
Amber |
3 |
SMD |
0.04 A |
114003AL |
Lamp only |
12V |
Amber |
3 |
SMD |
0.04 A |
114003R |
Chromed Base Mount Kit |
12V |
Red |
3 |
SMD |
0.04 A |
114003RL |
Lamp only |
12V |
Red |
3 |
SMD |
0.04 A |
114103A |
Black Base Mount Kit |
12V |
Amber |
3 |
SMD |
0.04 A |
114103R |
Black Base Mount Kit |
12V |
Red |
3 |
SMD |
0.04 A |
114012A |
Chromed Base Mount Kit |
12V |
Amber |
12 |
SMD |
0.06 A |
114012AL |
Lamp only |
12V |
Amber |
12 |
SMD |
0.06 A |
114012R |
Chromed Base Mount Kit |
12V |
Red |
12 |
SMD |
0.06 A |
114012RL |
Lamp only |
12V |
Red |
12 |
SMD |
0.06 A |
114112A |
Black Base Mount Kit |
12V |
Amber |
12 |
SMD |
0.06 A |
114112R |
Black Base Mount Kit |
12V |
Red |
12 |
SMD |
0.06 A |
114000MB |
Spare 4"×1" Rectangular Mounting Bracket, Black Plastic |
|||||
114000MC |
Spare 4"×1" Rectangular Mounting Bracket, Chromed Plastic |
